Advantage1. Good after - sale service : A good after - sale is not only to
make the customer feel satisfied with the product , but also to
feel that the customer is satisfied with the service so it is
necessary to do a good after - sales service .
2. Good service attitude : There is a good service attitude , such
as the problem of the product , after the situation , we will help
him solve the problem first time , as long as it is the customer's
request is reasonable , we will try to meet the customer as much as
possible .
3. Price advantage and Good product quality : We have our own
factory , the cost will be relatively low , customers are
acceptable prices , secondly , our product quality is also praised
by customers in the international market .
4. Strictly managed company system : With the strict company
management system , as long as the reference information and
accurate product are provided , we will follow the customer's
delivery date as much as possible .
List of spare parts
| # | Part No | Part Name | Qty. |
|---|
| N* | @ | FUEL INJECTION PIPE & NOZZLE
*-1, *-2 | 1 |
| *-1 | 31Q6-10130 | SWING MOTOR UNIT | 1 |
| *-1 | 31Q6-10131 | SWING MOTOR UNIT | 1 |
| 1 | XKAY-00637 | BODY | 1 |
| K2 | XKAY-00521 | SEAL-OIL | 1 |
| 3 | XKAY-00522 | BEARING-ROLLER | 1 |
| 4 | XKAY-00523 | RING-SNAP | 1 |
| 5 | XKAY-00524 | SHAFT | 1 |
| 6 | XKAY-00525 | BUSHING | 1 |
| 7 | XKAY-00526 | RING-STOP | 1 |
| 8 | XKAY-00625 | PIN | 1 |
| 9 | XKAY-00527 | PLATE-SHOE | 1 |
| A | XKAY-00635 | ROTARY KIT | 1 |
| A-A | XKAY-00634 | CYLINDER BLOCK KIT | 1 |
| N10 | XKAY-00633 | CYLINDER BLOCK | 1 |
| N11 | XKAY-00531 | SPRING | 9 |
| 24 | XKAY-00544 | PLATE-VALVE | 1 |
| A-B | XKAY-00532 | RETAINER KIT | 1 |
| N12 | XKAY-00533 | GUIDE-BALL | 1 |
| N13 | XKAY-00534 | PLATE-SET | 1 |
| A-C | XKAY-00535 | PISTON KIT | 1 |
| N14 | XKAY-00536 | PISTON ASSY | 9 |
| 15 | XKAY-00537 | PLATE-FRICTION | 3 |
| 16 | XKAY-00538 | PLATE | 3 |
| 17 | XKAY-00632 | PISTON-BRAKE | 1 |
| K18 | XKAY-00468 | O-RING | 1 |
| K19 | XKAY-00540 | O-RING | 2 |
| 20 | XKAY-00541 | SPRING | 20 |
| 21 | XKAY-00630 | COVER-REAR | 1 |
| 22 | XKAY-00543 | BEARING-NEEDLE | 1 |
| 23 | XKAY-00382 | PIN | 2 |
| 25 | XKAY-00546 | WRENCH BOLT | 4 |
| 26 | XKAY-00309 | PLUG | 2 |
| K27 | XKAY-00141 | RING-BACK UP | 2 |
| K28 | XKAY-00310 | O-RING | 2 |
| 29 | XKAY-00311 | SPRING | 2 |
| 30 | XKAY-00312 | CHECK | 2 |
| 31 | XKAY-00976 | RELIEF VALVE ASSY | 2 |
| 32 | XKAY-00314 | REACTIONLESS V/V ASSY | 2 |
| 33 | XKAY-00315 | TIME DELAY VALVE ASSY | 1 |
| 33 | XKAY-01470 | TIME DELAY VALVE ASSY | 1 |
| 34 | XKAY-00149 | BOLT-WRENCH | 3 |
| 35 | XKAY-00150 | PLUG | 1 |
| K36 | XKAY-00151 | O-RING | 3 |
| 37 | XKAY-00140 | PLUG | 1 |
| 38 | XKAY-00975 | PLUG | 1 |
| 39 | XKAY-00548 | PLUG | 1 |
| 40 | XKAY-00549 | NAME PLATE | 1 |
| 40 | XKAY-01518 | NAME PLATE | 1 |
| 41 | XKAY-00277 | RIVET | 2 |
| 42 | XKAY-00638 | LEVEL GAUGE | 1 |
| 43 | XKAY-00551 | FLANGE | 1 |
| K44 | XKAY-00552 | O-RING | 2 |
| 45 | XKAY-00322 | PLUG | 2 |
| K46 | XKAY-00324 | O-RING | 2 |
| K47 | XKAY-00247 | O-RING | 2 |
| K48 | XKAY-00605 | RING-BACK UP | 2 |
| *-2 | @ | FUEL INJECTION PIPE & NOZZLE
SEE 4110 | 1 |
| K | XKAY-00553 | SEAL KIT
SEE ILLUST | 1 |
| K | XKAY-01517 | SEAL KIT
SEE ILLUST | 1 |
| N | @ | FUEL INJECTION PIPE & NOZZLE | AR |
FAQ :
Q1: Could you design products at my demand ?
A: We will do our best to manufacture it according to your request
.
Q2: How can you promise the quality ?
A: Usually , One year warranty against B / L date . If you meet
with quality problem , we promise to be responsible for it.
Q3: If we can not find what we want on your website , what should
we do ?
A: You can email us the descriptions and pictures of the products
you need , We will check whether we can have it .
Q4: Can we purchase some of your products for quality testing ?
A: Yes , of course , we are confident for our products . Welcome
customers to buy for quality testing .
Q5: What is the lead time ?
A: For swing gearbox , normally 3 days , 3 days and lead time is
calculated from the day we receive your deposit .
Exact time is determined by factory schedule .
